The APC Back-UPS XS 1500 is a reliable UPS providing surge protection and battery backup for home and small office equipment, ensuring uninterrupted power during outages.
1.1 Overview of the APC Back-UPS XS 1500
The APC Back-UPS XS 1500 is a high-performance uninterruptible power supply (UPS) designed to provide reliable backup power and surge protection for home and small office equipment. It ensures uninterrupted operation of critical devices during power outages or fluctuations. With a power capacity of 1500 VA and 865 watts, it offers sufficient backup time to save work and safely shut down systems. The unit features a compact design, easy installation, and user-friendly controls. Its energy-efficient mode helps reduce power consumption when idle. The XS 1500 is ideal for protecting computers, networking gear, and other sensitive electronics.
1.2 Key Features and Benefits
The APC Back-UPS XS 1500 offers surge protection, battery backup, and power saving modes to ensure devices remain safe and functional during outages. It provides 1500 VA capacity, with 865 watts of maximum load, delivering up to 3.1 minutes of backup at full load. The unit features automatic voltage regulation, energy-efficient operation, and a user-friendly design. Built-in USB and serial ports enable easy connectivity and monitoring. The XS 1500 supports external battery packs for extended runtime and includes a 1-year warranty, making it a robust solution for protecting critical electronics.
Product Specifications
The APC Back-UPS XS 1500 provides 1500 VA capacity and 865 watts of maximum load, with backup times of up to 3.1 minutes at full load and 13.1 minutes at half load. It operates within a temperature range of 32°F to 104°F (0°C to 40°C) and includes surge protection, automatic voltage regulation, and energy-efficient power-saving mode. The unit supports external battery packs for extended runtime and is backed by a 1-year warranty, ensuring reliable protection for critical electronics.
2.1 Technical Details and Ratings
The APC Back-UPS XS 1500 has a capacity of 1500 VA and 865 watts, providing reliable power protection. It operates within a temperature range of 32°F to 104°F (0°C to 40°C) and supports an external battery pack for extended runtime. The unit offers an efficiency rating of 80% and a typical recharge time of 24 hours. Dimensions are 12.2 inches tall, 5.5 inches wide, and 9;8 inches deep, with a weight of 20.7 pounds. It includes a one-year comprehensive warranty and supports APC’s dedicated customer service for technical assistance and replacements.
2.2 Power Capacity and Backup Time
The APC Back-UPS XS 1500 offers a power capacity of 1500 VA and 865 watts, ensuring robust backup support for essential devices. At half load (432.5 watts), it provides approximately 13.1 minutes of backup time, while at full load (865 watts), it delivers about 3.1 minutes. This allows users to safely shut down equipment or save critical work during power outages. The UPS also supports an optional external battery pack for extended runtime, making it suitable for small offices or home setups requiring reliable power protection.
Installation and Setup
The APC Back-UPS XS 1500 installation is straightforward, involving unpacking, placing the unit on a flat surface, and connecting devices. Ensure proper ventilation and power checks.
3.1 Unpacking and Physical Installation
Start by carefully unpacking the APC Back-UPS XS 1500 from its box, ensuring all components, including the UPS, battery cartridge, and cables, are included. Place the unit on a flat, stable surface in a well-ventilated area, avoiding direct sunlight or moisture. Connect the battery cartridge to the UPS as instructed in the manual. If using the pedestal, align and slide the UPS into place, ensuring proper alignment. Once installed, plug in the UPS and allow it to charge before connecting your devices;
3.2 Connecting the Battery Cartridge
After unpacking, locate the battery cartridge and ensure it is properly aligned with the UPS unit. Gently slide the cartridge into the designated slot until it clicks securely into place. Once connected, plug in the UPS to begin charging the battery. Allow the battery to charge for at least 24 hours before use to ensure optimal performance. The battery cartridge is replaceable, and a new one can be ordered directly from APC’s website if needed. Proper installation ensures reliable backup power during outages.
Operating Environment
The APC Back-UPS XS 1500 operates in temperatures between 32°F and 104°F (0°C to 40°C) and humidity levels of 20% to 80%.
4.1 Temperature and Humidity Requirements
The APC Back-UPS XS 1500 requires an operating temperature of 32°F to 104°F (0°C to 40°C) and a relative humidity of 20% to 80% non-condensing. Proper ventilation is essential to prevent overheating. Avoid placing the UPS in direct sunlight, near heating vents, or in excessively moist environments. Ensure the device is positioned in a well-ventilated area to maintain optimal performance and longevity. Extreme temperatures or humidity levels may affect battery life and overall functionality. Always follow the recommended environmental guidelines for reliable operation.
4.2 Placement and Ventilation Guidelines
The APC Back-UPS XS 1500 should be placed in a well-ventilated area to ensure proper airflow and prevent overheating. Avoid positioning it in direct sunlight, near heating vents, or in areas with high humidity or moisture. Keep the UPS upright to maintain stability and prevent damage. Allow at least 2 inches of clearance around the unit for optimal cooling. Proper placement and ventilation are crucial to extend the lifespan of the battery and ensure reliable performance. Always follow the recommended guidelines in the user manual for ideal operating conditions.
Features and Functionalities
The APC Back-UPS XS 1500 offers surge protection, battery backup, and energy efficiency to safeguard devices while optimizing power usage during outages.
5.1 Surge Protection and Battery Backup
The APC Back-UPS XS 1500 provides premium surge protection, safeguarding electronics from voltage spikes and fluctuations. Its battery backup ensures uninterrupted power during outages, allowing users to save work and shut down safely. The UPS supports devices like computers, monitors, and routers, delivering reliable backup power. With a capacity of 1500 VA/865 W, it offers approximately 3.1 minutes of runtime at full load and 13.1 minutes at half load. This feature-rich system is ideal for protecting critical equipment in homes and small offices.
5.2 Energy Efficiency and Power Saving Mode
The APC Back-UPS XS 1500 incorporates advanced energy-efficient features, including a power-saving mode that reduces standby power consumption. This UPS automatically turns off the transformer when input voltage is stable, minimizing energy waste. The system also supports automatic voltage regulation, which reduces battery usage during normal operation. These features not only lower utility costs but also prolong the lifespan of the battery. By optimizing power delivery, the XS 1500 ensures efficient performance while maintaining reliability for connected devices, making it an eco-friendly choice for home and small office setups.
Connecting Equipment
The APC Back-UPS XS 1500 provides multiple outlets for connecting devices. Critical equipment like computers and routers should be plugged into outlets offering both surge protection and battery backup, while less critical devices can use surge-only outlets. This ensures optimal power delivery and protection during outages and voltage fluctuations.
6.1 Identifying and Using Correct Outlets
The APC Back-UPS XS 1500 features distinct outlets for different power needs. Identify the correct outlets by their labels: some provide both surge protection and battery backup, while others offer surge protection only. Critical devices like computers and routers should be connected to outlets with both features to ensure uninterrupted operation during outages. Less critical equipment, such as printers or fax machines, can be plugged into surge-only outlets. Proper outlet usage ensures efficient power distribution and maximizes protection for connected devices during power fluctuations or outages.
6.2 Connecting Phones, Modems, and Fax Machines
To connect phones, modems, and fax machines to the APC Back-UPS XS 1500, use the dedicated data lines or surge-protected outlets. Ensure these devices are plugged into the correct ports to avoid damage from power surges. For phones and modems, connect them to the RJ-11 or RJ-45 ports, depending on the device’s requirements. Fax machines should be connected to surge-protected outlets to prevent voltage spikes. Properly securing these connections ensures uninterrupted communication and protects sensitive equipment during power fluctuations or outages.
Maintenance and Troubleshooting
Regularly check the battery and connections for optimal performance. Replace the battery cartridge if alarms indicate a problem. Refer to the manual for troubleshooting common issues.
7.1 Replacing the Battery Cartridge
To replace the battery cartridge in your APC Back-UPS XS 1500, start by turning off the UPS and disconnecting it from the power source for safety. Open the unit to access the battery compartment, usually located at the bottom or rear, depending on the model. Release the battery cartridge by removing any screws or clips that secure it in place. Carefully pull out the old battery and dispose of it properly, following local regulations for battery disposal. Insert the new battery cartridge, ensuring it is securely fastened with the provided screws or clips. Close the compartment, reconnect the UPS to the power source, and allow the battery to charge fully before testing the system. This process ensures your UPS continues to provide reliable backup power during outages.
7.2 Common Issues and Solutions
Common issues with the APC Back-UPS XS 1500 include the UPS not turning on, battery faults, or overload problems. If the UPS fails to power on, check the circuit breaker and ensure all connections are secure. For battery faults, replace the battery cartridge with a compatible one. Overload issues can be resolved by reducing the connected load. Additionally, ensure the UPS is placed in a well-ventilated area to prevent overheating. If problems persist, refer to the troubleshooting guide or contact APC customer support for assistance. Regular maintenance and updates can help prevent these issues.
Warranty and Support
The APC Back-UPS XS 1500 comes with a 1-year warranty. For support, visit APC’s official website or contact their customer service for assistance and replacement options.
8.1 Warranty Terms and Conditions
The APC Back-UPS XS 1500 is covered by a 1-year limited warranty. The product was discontinued in September 2021, with end-of-service in November 2022, meaning no further official support. Replacement batteries (part number RBC33) are available for purchase. Warranty terms do not extend beyond the specified period, and users are advised to contact APC customer care for post-warranty assistance or additional support needs.
8.2 Contacting APC Customer Service
For assistance with the APC Back-UPS XS 1500, users can contact APC customer service through various channels. Visit the official APC website at www.apc.com for support resources, including FAQs, manuals, and contact details. Telephone support is available for technical inquiries, and email assistance can be accessed through the website. Replacement parts, such as the RBC33 battery cartridge, can also be ordered online or via customer service. Ensure to have the product serial number ready for efficient support.
